TCL 20 L
An affordable featured pack phone, with a durable battery life and TÜV Rheinland Circular Polarization certification
About
Specifications
PR Images
TCL 20 L
Immersive Display and Sustained Battery Life
The TCL 20L is a budget friendly, value-packed phone with a beautiful 6.67 inch screen and TÜV Rheinland-certified Circular Polarization Display technology. The device can last two days in typical use so you don't have to worry about being stuck somewhere without power. It also comes with fast-charging capabilities that are optimized by our built-in Smart Manager, which offers suggestions for fantastic performance and battery life thanks to the 5,000 mAh battery.

With the TCL 20L, setting yourself apart with the NXTVISION versatile 48MP quad camera will provide you all the tools you need to create such as wide-angle, macro and bokeh cameras. Also included is the 16MP selfie camera that will take your photos to the next level.

TCL 20L comes with 128GB storage and supports micro SD Card up to 1TB.

The TCL 20L will be soon available in several European markets for €229 in comes in Luna Blue and Ellipse Black.

To learn more about TCL Mobile devices, including the TCL 20 Series, please visit http://www.tcl.com/global/en.html
Display

6.67-inch dotch display

FHD+ Display
(1080 x 2400 resolution)

Screen-to-body ratio: 91%
(calculated with VA/TP method)

20:9 display ratio

1500: 1 contrast ratio (typical)

395 PPI, 16.7M colors, NTSC 82%, 500 nits brightness (peak)

Capacitive touchscreen





Design

Dimensions:
166.2*76.9*9.1mm

Weight:
199g

Finish:
2.5D front glass, 3D PMMA/PC back, high polished

Colors available:

Eclipse Black / Luna Blue

Side keys:
3
(1 for power & side finger print 2-in-1, 1 for volume, 1 for Google Assistant)


Specifications
Memory
T774H:
4 GB RAM (LPDDR4x) + 128 GB (eMCP)

Supports micro SDXC Card up to 1TB (FAT32)

*Actual internal storage available may vary depending on pre-installed software.
Battery
Battery:
5000mAh (typical)

9V 2A supportive

Type-C USB 2.0

Charging time:
3.1 hours (5V 2A) 2.5 hours (9V 2A)

DOU Value:
≥ 16 hours

Rear camera
48MP main camera:
48MP: AF, sensor size 1/2", pixel size 0.8μm, aperture F2.0, field of view 80.3°, 5P lens

8MP wide-angle camera:
FF, sensor size 1/4", pixel size 1.12μm, aperture F2.2, field of view 118°, 5P lens

2MP macro camera:
FF, sensor size 1/5", pixel size 1.75μm, aperture F2.4, field of view 83°, 3P lens

2MP depth camera:

FF, sensor size 1/5", pixel size 1.75μm, aperture F2.4, field of view 83°, 3P lens

Video capture:

1080p@60fps

Video playback:

1080p@60fps

Features:

LED flash, 2 x lossless zoom, HDR, Snapshot in video recording,
Face detection, Scene detection 2.0, Google lens, Pro Mode, Panorama, Light Trace, Wide-angle mode, Super Macro, Portrait Mode, Slow-mo video, Stop motion
Front camera
16MP front camera:
16MP: FF, sensor size 1/3.1'', pixel size 1.0μm, aperture F2.2, field of view 76.3°, 5P lens

Video capture:
1080P @30FPS

Video playback:
1080P @30FPS

Features:

LCD flash, Face Beautification, Portrait Mode, HDR, Face detection, Slow motion

Audio
Audio playback format:
AAC LC, AAC+, enhanced AAC+, AMR-NB, AMR-WB, FLAC, MP3, MIDI, Vorbis, PCM/WAVE

Dual-mic noise cancellation, HD Voice

Speakers:
2 (one speaker, one receiver as mini speaker)

Supported headsets: LRGM
Support SBC, AAC, apt-X, LDAC, apt-X, apt-X HD, apt-X LL Bluetooth audio codec

Super Bluetooth:
connect up to 4 Bluetooth devices to play audio simultaneously 2 3.5mm audio jack
(only supports two devices when connected to a 2.4 GHz Wi-Fi network)

Connectivity
2G Bands:
GSM 850/900/1800/1900

3G Bands:
B1/2/5/8

4G Bands:
B1/3/5/7/8/20/28/38/40/41 (2535~2655 MHz)

2G data:
GPRS/EDGE, Class 12

3G data:

HSPA+ (42M bit/s DL, 5.76 Mbit/s UL)

4G data:
CAT6

Wi-Fi 802.11a/b/g/n/ac
Wi-Fi Direct

4G Mobile Hotspot, VoLTE, VoWiFi

Bluetooth 5.0, Type-C USB 2.0, NFC

Dual SIM model:
1 4FF Nano + 1 4FF Nano or 1 TF Card

Single SIM model:
1 4 FF Nano SIM + 1 TF Card

Features
OS:
TCL UI, Android™ 11 (support 1 OS upgrade)

Chipset:
Qualcomm® Snapdragon™ 662

CPU:
Qualcomm® Kryo™ 260 Octa-Core: 4x Gold 2.0 GHz,4x Silver 1.8GHz

GPU:
Qualcomm® Adreno™ 610

Location:
GPS, A-GPS, BeiDou, Galileo, Global Navigation Satellite System (GLONASS)

Other sensors:

Accelerometer, proximity, light, e-compass, Gyro

Authentication:

Face key, Fingerprint sensor (side)

Other features:
torch light, Radio

Inbox accessories:

Charger (9V2A), Type-C Cable, display & Back cover Film, SIM tooling pin, QSG, PSI, TPU case

Optional accessories:

Headset (WH35), PC case, screen protector film
